Capacity F(nom) (N ): 200
Resolution (N ): 0.1
Accuracy (% F(nom)): 0.05
Reproducibility (% F): 0.01
Repeatability( % F ): 0.01
Hysteresis (% F ): 0.025
Creeping (5min) (% F ): 0.05
Measuring principle : Bidirektionaler Kraftsensor mit Dehnungsmessstreifen
Nominal deflection( mm ): 0.17
Measuring shaft : M6
Display:
Type: LCD 4-digit | 12 mm
Refresh time (ms) : 50 ... 1000
Operation modes:
Regular: N | kgf | lbf
Peak (real-time) : Display of peak value | Peak value of pull- or push force (drag indicator function)
Limits + Statistik : 2 separately adjustable limits | Single value memory and continuous measured value memory
Interface:
USB : USB 2.0 data communication
Hirose: Limit / overload signals. digital I/Os (2 outputs)
Digimatic : yes
Power supply:
Type: interner NiMh-Akku | Batteriestandzeit 12h
Charging : Mains / Charger 85 ... 240VDC (50 ... 60Hz)
Temperature (operation) (°C): 0 ... 40
Protection code (EN 60529): IP00
Housing:
Material : AL-Druckguss
LxWxH (mm) : 147 x 75 x 38
Weight (kg) : 0.45
Mounting : 4 x M4x6
