Single module Number of channels: 8 analog input channels; max measuring channels :8
Maximum sampling rate: 80KS / s / chassis
Sampling modes: multi-channel simultaneous sampling
ADC resolution: 24
Supported strain Gage Resistance: 120/350Ω
Wheatstone bridge type: 1/4 bridge
Conversion accuracy: 3.5062nV/V/LSB
Accuracy gain error: 0.02% (calibrated conventional measurement conditions 25 ° C ± 5 ° C)
Full-scale range: ± 29.4mV / V (+62500 uE/-55500uE)
Between terminals Overvoltage protection: ± 30V
Stability: Gain drift 6ppm / ℃
The Chassis Interface Type: USB2.0 high speed input
Power supply: 11 to 30VDC, 220VAC
Operating Temperature: -40 ℃ ~ 70 ℃, Operating Humidity: 10% ~ 90% RH, non-condensing
Storage Temperature: -40 ° C to 85 ° C, storage humidity: 5% to 90% of RH, non-condensing
Protection class: IP 40
