Light control setting system: Digital setting (8 bits, 256 gradations)
Output control method: PWM control (56 ±5 kHz)
Number of outputs: 1ch
Output voltage: 24 VDC (±0.5V)
Maximum output current: 1.12A
Maximum output capacity: 27W
External ON/OFF:
+ With external ON/OFF control (pin open: lit, short-circuited: unlit)
+ Logic inversion of ON/OFF control is enabled by the internal settings
External light control: With external light control (8 bits, 256 gradations)
Input voltage, frequency: 100 VAC to 240 VAC, 50/60 Hz (worldwide)
Output connector/polarity: SMP-04V-BC (J.S.T. Mfg.) / 1: NC, 2: +(DC24V), 3: -(GND), 4: NC
External control connector: DALC-J15SA-23 (Dsub 15 pins)
External control input specification:
+ 1: COM, 2 to 9: D0 to D7
+ 10 to 11: ON/OFF
+ 12: +5V, 13:GND, 14to15:NC
Outer dimensions L1: 173
Outer dimensions L2: 141
Usage environment: Temperature: 0°C to 40°C, humidity: 20 to 85RH (no condensation), indoor lighting equipment
Storage environment: Temperature: 0°C to 60°C, humidity: 20 to 85RH (no condensation)
Cooling system: Natural air cooling
Mass: 650g
