Input
Capacity: 5kVA
Number of phases: Single phase two wire + PE
Voltage: Phase voltage 220V ±10%
Frequency: 50/60Hz ±3Hz
Output
Rated current:
110V: 45.6A
220V: 22.8A
Setting accuracy:
Voltage: Resolution: 0.1V Precision: 0.2% x reading value + 0.1% x full scale value
Frequency: Resolution: 0.1Hz Precision: 0.05%
Testing accuracy:
Voltage: Resolution: 0.1V Precision: 0.2% x reading value + 0.1% x full scale value
Frequency: Resolution: 0.1Hz Precision: 0.05%
Current: Resolution: 0.001A/0.01A/0.1A Precision: 0.3% x reading value + 0.3% x full scale value
Power: Resolution: 0.001kW/0.01kW Precision: 0.45% x reading value + 0.45% x full scale value
Efficiency: >80%
Function
Display mode: 4.3" color LCD touchscreen
Communication: Standard RS232, opt. RS485/GPIB/Ethernet
Working environment
Temperature: 0 - 40°C
Humidity: 20 - 90%RH
Dimensions W x H x D (mm): 11U, 432 x 488 (563) x 400
Weight (kg): 59
