Capacity: 30 kVA
Input
Phase: 3-phase 4-wire+PE
Voltage: Phase voltage: 220V±33V, line voltage: 380V±57V
Frequency: 50/60Hz±3Hz
Phase: Single-phase and two-wire
Output
Current: 4000A
Voltage: 7.5V
Frequency: 45.0-65.0Hz
Testing accuracy
Current:
Resolution: 0.1A
Accuracy: 0.3%xReading value+0.3%xFull range value
Frequency:
Resolution: 0.1Hz
Accuracy: 0.1%
Voltage:
Resolution: 0.01V
Accuracy: 0.3%xReading value+0.3%xFull range value
Power:
Resolution: 0.1kW/0.01kW/0.001kW
Accuracy: 0.45%xReading value+0.45%xFull range value
Frequency stability: ≤0.02%
Voltage distortion: Linear load THD<2%
Voltage crest factor: 1.41±0.1
Protection mode: lGBT overheat, lGBT overcurrent, transformer overheat, input overvoltage,input undervoltage, output overvoltage, output overcurrent, and output overload
Function
Display: 8inch LCD
Online adjustment function: Output current and frequency can be adjusted online
Memory: Power-off memory function, memory last output mode and parameters
Communication: RS232 (standard) and RS485 (optional)
Operating environment
Temperature: 0-40℃
Humidity: 20-90%RH
Dimensions(WxHxD mm): 600x1330x1018
*Images for illustration purposes only
