Withstanding voltage
• Output voltage:
Range: (300 ~ 3000) VAC; Step: 10V
Accuracy: ± (2.5%x setting +10V); Distortion: <3%
• Output frequency:50Hz/60Hz; Accuracy: ±0.1Hz
• Actual capacity: ≥ 90%
• Breakdown current:
Range: (0.10~20.00) mA
Accuracy: ± (2.5%x reading +5 counts)
• Duration: Range: (1~99) s; Accuracy: ± (1 %x setting +0.1s)
• Arc: Level-0 to 9, 0: Arc Off
Insulation Resistance
• Output voltage:
Range: (200 ~ 1000) V DC; Step: 5V
Accuracy: ± (3%x setting +5V)
• Ripple coefficient: <5%
• Resistance measurement:
Range: (1.0 ~ 99.9) M Ω, (100 ~500) M Ω
Accuracy: ± (3%x reading +5 counts), ≤200M Ω; ± (5%x reading +8 counts), >200M Ω
• Duration: Range: (1~99) s; Accuracy: ± (1 %x setting +0.1s)
Resistance
• Resistance measurement:
Range: 0.1/ 2/20/200/2k/20k, unit: Ω
Accuracy: ±(0.3%x reading +3 counts) (temperature compensation off)
• Temperature measurement: Range: (0.0~60.0)°C; Accuracy: ±0.5°C
Inductance
• Inductance measurement:
Range: 0.1μH~2H
Frequency: 1kHz
Test level: 1V
Accuracy: ± 1% x reading
Back EMF
• Voltage
Range: 0.5-50V (rms)
Accuracy: ± 0.3% x reading
Speed range: 100-3000 rpm
Speed accuracy: ± 1% x reading + 2 turns
