Input:
Voltage: 3-phase 3-wire + PE, 340V ~ 420VAC
Frequency: 47 ~ 63 Hz
Output:
Voltage: 0～750V
Current: 0～60A
Power: 15kW
Display Mode: 4.3" Color LCD screen
Testing Accuracy:
Voltage: ≤0.1% of Umax, Resolution: 0.01V
Current: ≤0.2% of Imax, Resolution: 0.01A (for >1000A, 0.1A)
Power: ≤1% of Pmax, Resolution: 0.001kW (for >100kW, 0.01kW)
Ripple and Noise 20Hz ~ 20MHz:
Vrms: 200mV
Vpp: 800mV
Load Effect Voltage: ≤0.05% of Umax, Current: ≤0.15% of Imax
Source Effect Voltage: ≤0.02% of Umax, Current: ≤0.05% of Imax
Transient Response Time: ≤2ms
Rise Time 100%: 50ms (10% - 90%)
Maximum Output Voltage Drop Compensation: 25V
Communication Standard: RS232, Optional: RS485, LAN, GPIB
Environmental Temperature: 0 ~ 40 ℃; Humidity: 20 ~ 90% RH
Dimensions W × H × D (mm): 440 × 133 × 595
Weight: 37kg.
