Input: 3-phase 3-wire +PE ,340V~420VAC,47-63HZ
Output
Voltage: 0~750V
Current: 0~20A
Power: 0~5kW
Display mode: 4.3'' color LCD
Resolution/Accuracy
Voltage: ≤0.1%Umax, Resolution:0.01V
Current: ≤0.2%Imax, Resolution:0.01A (>1000A, 0.1A)
Power: ≤1%Pmax, Resolution: 0.001kW(>100kW, 0.01kW)
Ripple and Noise 20Hz~20MHz
Vrms: 200mV
Vpp: 800mV
Load effect: Voltage:≤0.05%Umax, Current: ≤0.15%Imax
Source effect: Voltage:≤0.02%Umax, Current:≤0.05%Imax
Transient response time: ≤2ms
Rise time 100%: 50ms(10%-90%)
Max output voltage drop compensation: 25V
Communication: Standard RS232,Optional RS485,CAN,LAN,GPIB,Analog interface
Protection: reverse, current limiting, S terminal compensation ,Input phase loss protection, output overvoltage, overheat, short circuit protection
Parallel: Support multiple parallel outputs to expand the power/current range
Environment: Temperature: 0~40ºC; Humidity: 20~90%RH
Dimension W×H×D(mm): 440×133×595
Weight: 17kg
