Frequency Range (operating, 100 gram payload): 7 Hz to 10 kHz
420 to 600 k cpm
Maximum Amplitude (100 Hz with no payload): 20 g pk (196 m/s2 pk)
Maximum Payload: 800 gram
Accuracy
Acceleration (30 Hz to 2 kHz): ±3%
Acceleration (7 Hz to 10 kHz): ±1 dB
Velocity (10 Hz to 1000 Hz): ±3%
Displacement (30 Hz to 150 Hz): ±3%
Amplitude Linearity (100 gram payload, 100 Hz): < 1% up to 10 g pk
Waveform Distortion (100 gram payload, 30 Hz to 2 kHz): < 5% THD (typical) up to 5 g pk
READOUT
Acceleration (peak and RMS): g, m/s2
Velocity (peak and RMS): in/s, mm/s
Displacement (peak to peak): mils, μm
Frequency: Hz, CPM
POWER
Internal Battery (sealed solid gel lead acid): 12 VDC, 6 amp hours
AC Power (for recharging battery): 110-240 Volts, 50-60 Hz
Operating Battery Life
100 gram payload, 100 Hz 1 g pk: 12 hours
100 gram payload, 100 Hz 10 g pk: 1 hours
PHYSICAL
Dimensions (H x W x D): 8.5 in x 12 in x 10 in(22 cm x 30.5 cm x 28 cm)
Weight: 18 lb (8.2 kg)
Sensor Mounting Platform Thread Size: 1⁄4-28
Included:
ACC- 100 Short Handle Wrench
CAB 100 -Micro Dot (10-32) Cable
MNT-104 ¼-28 Stud
MNT-105 - 10-32 UNF Stud
MNT 106 - 2-56 UNC Adapter
MNT 107 -6-32 UNC Adapter
MNT- 111 10-32 UNF Adapter
