Stardard Number Of Channels: 1 (CH1)
Accuracy: ≤± 0.010 %
Linearity Error: ≤± 0.010 %
Internal Divisions: 24 bit
Input Ch1: Strain Gauge Transducers: ± 2 mV/V and ± 3 mV/V (max ± 3.5 mV/V)
Resolution: ± 100.000div
Transducers Power Supply: 5 Vdc switching (± 3 %)
Type Of Connection: 4 or 6 wires
Transducer Resistance: from 100 Ω to 2000 Ω
Transducers Connected In Parallel: For each channel: 4 to 350 Ω or 8 to 700 Ω
Input Ch1: Voltage Amplified Transducers: ± 10 V and ± 5 V
Resolution: ± 100.000 div
Transducers Power Supply: 20 Vdc (± 1 Vdc)
Input Ch1: Current Amplified Transducers: 0-20 mA ; 4-20 mA
Resolution: + 200.000 div ; + 160.000 div
Transducers Power Supply: 20 Vdc (± 1 Vdc)
Input Ch1: Potentiometer: R min. 1 kΩ
Power Supply: 5 Vdc
Unit Conversions For Weight And Force : kg, t, N, daN, kN, MN, lb, klb
Unit Conversions For Pressure : bar, mbar, psi, MPa, kPa, Pa, mH2O, inH2O, kg/cm2, mmHg, cmHg, inHg, atm
Unit Conversions For Torque : N⋅m, N⋅mm, kN⋅m, kg⋅m, g⋅cm, kg⋅mm, ft⋅lbf, in⋅lbf
Unit Conversions For Displacement : mm, m, foot, inch, cm, dm, µm
Multimeter Function : Direct Display in mV/V, Volt or mA
Backlit Graphic Display: 128 x 64 dots
Character Size: ∼ 13 mm
Adjusting Display Contrast: YES
Transducer Calibration: Both in the POSITIVE and NEGATIVE range
Type Of Digital Calibration: Full Scale, Point Interpolation, Known Weight
Field Linearitation: On 1 … 5 measurement point
Backup And Restore Function: Save and restore all configuration data
Function Of Zero: 100% (on all the measurement range)
Function Of Autozero: With TIME and THRESHOLD programming
Function Of Peak: POSITIVE and NEGATIVE
Function Of Discharge: YES
Functione Counting: YES
Function Of Key Block: Enabled through a Password
Function Of Total (Ch1+Ch2): YES
Programmable Resolution: 1 … 100
Digital Filter: 0 … 5
Programmable Decimal Position Point: 0 … 5
Programmable Conversion Rate: from 2.5 to 4800 samples for second
Instrument Language: ITALIAN and ENGLISH
Function Keys Programmable In Configuration: F1 – F2 – F3 – F4
Set Point Programmable: 5
Programmable Digital Inputs: 4
Relay Output (Dpdt Form): 4
Max Tension: 220 Vdc – 250 Vac
Max Current: 2A
Max Power: 60 W – 62,5 VA
Rear Panel Usb Output, Connector Type B : Max Cable Length 3.5 m
Nominal Working Temperature: 0... +50 °C
Max Working Temperature: 0... +50 °C
Storage Temperature: -20... +70 °C
Temperature Effects On Zero (10°C Variation): ≤±0.005 %
Temperature Effects On Full Scale (10°C): ≤±0.005 %
Power Supply: 230 Vac +/-10 %
Frequency: 50/60 Hz
External Protection Fuse: 250mA / 250 V
Max. Power Required: 10 VA
Panel Mounting Case: DIN 43700
Case Material: NORYL UL94 V-O
Front And Rear Panel Material: UL94 V-2
Protection Class (En 60529): IP40 (only front panel)
Degree Of Environmental Cont.: 1
Dimensions (H X L X D): 72 x 144 x 150 mm
Drilling Template (A X L): 68 x 138 mm
Weight: ∼ 0.8 kg
