Input
- Input Voltage Range: Universal input 47 ~ 440 Hz: 85~264 VAC
120~380 VDC
- Power Rating: 504W Nom
- Input Current: 5A
- Inrush Current 230 VAC @ 25°C: 25A
- Undervoltage Lockout: Shutdown, 65 ~ 74 VAC
- Fusing: 250V, F8A HRC
Output
- Output Voltage Range: 19~28VDC
- Output Current Range: 21A Max
- Load and Cross Regulation: For 25% ~ 75% load change, ±0.2 %
- Line Regulation: For ±10% change from nominal line, ±0.5%
- Ripple and Noise: 240mV pk-pk
General:
- Isolation Voltage:
Input to output: 4000 VAC
Input to chassis: 1500VAC
Output to chassis: 1500VAC
- Efficiency: 230 VAC, 1008 W @ 24 V, > 92% Nom
- Leakage Current: 264 VAC, 60 Hz, 25°C, 300μA
- Bias Supply: Always on, current 50 mA, 12.0VDC Nom
Environmental
- Operating Temperature: +70 °C Nom
- Storage Temperature: +85°C Nom
- Relative Humidity: Non-condensing, 5 ~ 95 %RH
- Weight: 1.1 kg
