- Input Voltage Vin (Pins 1 and 2): 5 ±0.5 (2 ~ 3 kV ONLY)
- Input Voltage: 5V (2 ~ 3 kV ONLY)
- Input Current: No load: 55mA, full load: 450mA
- Input Voltage: 15V (600 V ~ 1.5 kV ONLY)
- Input Current: No load: 40mA, full load: 190mA
- Polarity: Fixed positive or negative
- Output Voltage: 0 ~ 600VDC
- Input Voltage: 12VDC, 15VDC, 24VDC
- Output Power: 0.5W, 0.8W, 1W
- Output Current: 0.83mA, 1.33mA, 1.67mA
- HV Setting: 10 ~ 100 K (potentiometer across Vref. and signal ground, wiper to adjust)
- Load Voltage Regulation: < 0.01% VDC of full output voltage for no load to full load
- Line Voltage Regulation: < 0.01%VDC of full output voltage over specified input voltage range
- Residual Ripple: < 0.01%V pk ~ pk at full load
- Temperature Coefficient: 100PPM/°C for the max output voltage after starting and over temperature range 0 ~ 50°C
- Output Current Monitoring:
600 ~ 1500 V: +1 V/1 kV max or -1 V/-1 kV max according to model polarity output impedance = to 200 kΩ ±1%
2 ~ 3 kV (12 ~ 24 V input only): 0 ~ +5 V±2%
2 ~ 3 kV (5 V inputs): 0 ~ +2.5 V±2%
- Reference Voltage:
12 ~ 24 V input only: 5 V ±1%, TC: 100 ppm/°C, max output current: 1 mA
5 V inputs: 2.5 V ±1%, TC: 100 ppm/°C, max output current: 1 mA
- Operating Temperature: -10 ~ +65°C, full load, max Eout, Tcase temp
- Storage Temperature: -40 ~ +70°C
- Safeguards: Arc and short-circuit protection
- Options: Shielded flying lead for HV output
Construction:
Casing: Steel, tin-plated thickness 0.5 mm (0.02")
Insulation: Silicone-based RTV (contact factory for other options)
Volume: 16.4 cc (1.00 in3)
Weight: 35 g (1.23 oz)
Tolerance
- Overall: ±0.76 mm (0.030")
- Pin to Pin: ±0.38 mm (0.015")
- Pin to Tab: ±0.51 mm (0.020")
- Tab to Tab: ±0.25 mm (0.010")
