- Output Power: 1 kW maximum at full rated output voltage and current
- Output Voltage: Units available with maximum output voltages from 1 ~ 60kV
- Output Current: Up to 1 A for 1 kV and 16 mA for 60 kV
- Input Voltage: 187 VAC ~ 255 VAC 47-63 Hz single phase plus protective earth
- Input Current: Less than 12 A
- Specification Range: Specifications apply above 5% of rated output voltage. The output can be controlled down to less than 0.25% of rated output voltage.
- Recovery Time: Less than 500 ms to within 0.1% of previous operating level following a short circuit or arc. Maximum overshoot 2% of rated output voltage.
- Temperature Coefficient: Less than 200 ppm/°C
- Drift: Less than 0.02% per hour after 1 hour warm up
- Operating Temperature: 0°C ~ +40°C
- Storage Temperature: -20°C ~ +70°C
- Humidity: 80% maximum relative humidity up to 31°C, reducing linearly to 50% at 40°C. Non-condensing (ref BS EN61010-1)
- Altitude: Sea level up to 2000 metres (6500 feet)
- Usage: Indoor use only
- Voltage Ripple:
Voltage Mode: Less than 0.1% of rated output voltage +2 V, peak to peak
Current Mode: Less than 0.5% of rated output voltage peak to peak
- Voltage Regulation:
Line: Less than 0.05% +1 V change in output voltage for a 10% change in line voltage
Load: Less than 0.05% +1 V change in output voltage for a 0 to 100% change in load current.
- Current Regulation:
Line Less than 0.5% of rated output current for a 10% change in line voltage
Load Less than 0.5% change of rated output current for a 0 to 100% change in output voltage
- Dimensions (W x D x H): 42.5 x 50.5 x 8.8 cm3 (17 x 19.7 x 3.4 in3)
- Weight: 14 kg
- Interface:
Analog remote-control interface is standard; control is via a 25-way female D-type connector
Digital control is optional
- Options & Accessories
Positive or negative polarity
Analog meter or blank front panel
HV output cable — 3 m, 5 m, or 10 m
