- Temperature Range: Ambient 5 ~ 300°C (41 ~ 572°F)
- Temperature Uncertainty: ±0.5% of reading ±1°C
- Temperature Resolution: 0.1°C
- Stability: ±0.5°C per 8-hour period
- Source Non-Uniformity: Approximately ±2°C @ 250°C
- Heated Cavity Shape: Flat plate
- Exit Port Diameter: 57 mm (2.25”)
- Emissivity ε: 1.00 effective emissivity @ 8 ~ 14 μm
- Standard Calibration Method: Radiometric
- Temperature Sensor: Precision platinum RTD
- Warm-up Time: ~10 minutes from room temperature to 200°C
- Slew Rate to 1°C Stability:
~18° per min T < 250°C
~14° per min T > 250°C
- Slew Rate to 0.1°C Stability: ~Approximately 12 minutes between Δ 50 °C setpoints
Environmental
- Operating Ambient Temp: 0 ~ 50°C (32 ~ 122°F)
- Cooling: Self-convection
- Operating Humidity: <90% non-condensing
- Dimensions (H x W x D):
Blackbody Source: 203 mm x 89 mm x 98 mm (8” x 3.5” x 3.86”)
Controller: 102 mm x 178 mm x 127 mm (4” x 7” x 5”)
- Weight:
Blackbody Source: 0.9 kg (2.0 lbs)
Controller: 0.70 kg (1.5 lbs)
- CE Certified: No
Communication and Electrical Specifications
- Method of Control: Digital PID controller
- Power Requirements: 230 VAC @ 50 and 60 Hz 300 W
