- Temperature Range: 200 ~ 1150°C (392 ~ 2102°F)
- Temperature Uncertainty: ±0.25% of reading ±1°C (when using Calibration Certificate correction factors)
- Temperature Resolution: 0.1°C
- Stability: ±0.5°C per 8-hour period
- Source Non-Uniformity: ±0.1% of reading ±1°C
- Heated Cavity Shape: Spherical
- Exit Port Diameter: 51 mm (2”)
- Emissivity ε:
1.0 effective @ 0.65 ~ 1.8 μm
~0.998 for others
- Standard Calibration Method: Radiometric (pyrometric)
- Temperature Sensor: Thermocouple
- Warm-up Time: 60 minutes from ambient to 1000°C
- Slew Rate to 1°C Stability:
~5° per min ambient to 200°C
~12° per min 300 < T < 800°C
~8° per min avg T > 800°C
- Slew Rate to 0.1°C Stability: ~60 minutes between Δ 100°C setpoints
Environmental
- Operating Ambient Temp: 0 ~ 44°C (32 ~ 110°F)
- Cooling: Fan cooled, air inlet on top panel
- Operating Humidity: 90% RH max, non-condensing
- Dimension (H x W x D): 640 mm x 500 mm x 572 mm (25.2" x 19.7" x 22.5")
- Weight: 80 kg (175 lbs)
- CE Certified: Yes
Communication and Electrical Specifications
- Remote Set Point: Via serial port
- Method of Control: Digital self tuning PID controller
- Power Requirements: 208/230 VAC ±10% 50/60 Hz 11A Max
Optional Accessories:
Cold aperture wheel assembly, 6 apertures 25.4 to 2.54 mm - PN 14002-1
Cold aperture wheel assembly, 6 apertures 50 to 1.56 mm - PN 14002
IGA 12-TSP, 1570 nm, 200” 1020°C, through-lens-sighting, laser targeting, focusable Optics 2 - PN 3840810
IGA 12-TSP, 1570 nm, 250” 1400°C, through-lens-sighting, laser targeting, focusable Optics 2 - PN 3840820
Serial Communication Output RS485 (built-in ex works) - PN 19140-485
