- Temperature Range: 200 ~ 1020°C
- Optics:
3 focusable optics:
275 ~ 520 mm
385 ~ 1125 mm
540 ~ 9000 mm
- Spectral Ranges: 1570 nm
- Resolution:
Up to 1000°C: 0.01°C on interface and display;
Above 1000°C: 0.1°C on display, 0.01°C on digital interface < 0.025% of temperature range at the analog output
- Measurement Uncertainty (ε = 1, t90 = 1 s, Tamb = 23°C):
< 1500°C: 0.15% of measured value in °C + 1°C
≥ 1500°C: 0.25% of measured value in °C
≥ 2700°C: 0.35% of measured value in °C
- Repeatability (ε = 1, t90 = 1 s, Tamb = 23°C): 1°C
- Emissivity ε: 0.100 ~ 1.000 in 1⁄1000 steps
Electrical:
- Power Supply: 24 VDC (15 ~ 40 VDC), or 24 VAC (12 ~ 30 VAC), 48 ~ 62 Hz
- Power Consumption: Max 14 W
Environmental
- Protection system: IP65 (according to DIN 40 050)
- Ambient Temperature: 0 ~ 60°C (32 ~ 140°F) at the housing
- Storage Temperature: -20 ~ 70°C (-4 ~ 158°F)
- Weight: 2.2 kg (≈2.20 lbs)
- CE Label: According to EU directives about electromagnetical immunity
Interface:
- Display: Built-in 5 digit LED display, additional function LEDs
- Control Panel: 4 keys, operate with tip of ball-point pen
- Sighting: View finder, laser targeting light
Communication:
- Analog Output: Linear 0 ~ 20 mA or 4 ~ 20 mA, DC, switchable; load max. 500 Ohm
- Test Current Output: Fixed 10 mA
- Serial Interface: Switchable at the pyrometer: RS232 or RS485 (addressable), half duplex; baud rate 2.4 up to 115 kBd
- Scope of Delivery: Instrument with one optics, case, power supply (service unit) NG 0S (100 ~ 240 VAC, 50 ~ 60 Hz ⇒ 24 VDC, 1 A) with 5 m connection cable to the pyrometer, PC analysing software InfraWin, work certificate according to ITS 90 (IS 12-TSP, 600 to 3000°C: work certificate up to 2500°C), user manual
