Measuring range and Accuracy (at 23℃ ±5℃ ), 180 days after calivration [In case of 1 year, the accuracy is the double]
% Measurement Display [0.063W when setting]
Measurement range: 10Ω/ 100Ω/ 1kΩ/ 10kΩ/ 100kΩ/ 1MΩ/ 10MΩ
Measurement voltage H/L: 0.24V ~ 50V/ 0.024V~5V
Read on catalog for Standard, Measurement voltage H/L, Accuracy by High measuring Voltage, Accuracy by Low measuring Voltage
Display: ±9.99％
Measuring method: 4 Terminal Measurement (High Measuring Voltage and Low Measuring Voltage)
Measuring time: Read on catalog
Comparator: HI, LOW ±9.99% LO, GO, HI judgment indication+output
I/O Signal :
Built-in DC12V Photo Isolation power
Ext. HOLD input：0-12V signal or Open, Short
Ext. START input：0-12V Signal or Open, Short (Available to change the logic)
Judgment result output：Open collector output NG, TOTAL GO
Measurement end output：Open collector output 1msec. to 99msec. (1msec/step), In case of zero setting Continuous
Warm up Time: over 30 minutes
Others: By the operation panel surface, zero and full-scale calibration function
Power supply: AC100V～240V slelctable, 50/60Hz
Outer dimension: about 333 (W) ×99 (H) ×300 (D) mm (excluding protruding parts such as rubber legs, etc.)
Weight: about 4kg
