Power supply: AC220V±10%, 50Hz
Voltage output: 0-80kV/100K
Accuracy: ±2%
Capacity: 1.6KVA, 2.0KVA
Pressure increase rate: About 2 KVA/s
Pressure testing speed: 2%
Break down sensitivity: <2KV
Wave form distortion: ≤3%
Time of breakdown: ≤10ms
Operational environment:
Temperature: 0℃-40℃
Humidity: the most relative humidity: 85%
Storage environment:
Temperature: -20℃-40℃
Humidity: the most relative humidity: 75%
Operational height: <150m (can be specially designed if the height is over 1500m)
Test cell: Glass, volume 300 to 500 ml, with protective cober and stirrer.
Electrodes: Stainless steel spherical 36 mm diameter/ hemispherical 25 mm radius, 2.5 mm gap as per IEC-156, or ASTM D 877 and ASTM 1816 (ASTM standard ar option)
Initial stand time of oil sample: 180 seconds
Intermediate stand time of oil sample: 60 seconds
String time of oil sample: 60 second
Number of consecutive test: 6
80KV: Weight: 50 kg, Dimension: 450*450*450 mm
100KV: Weight: 55 kg, Dimension: 480*480*480 mm
