Y-axis Travel: 500mm (customizable)
X-axis Travel: 350mm (customizable)
Maximum Spot Welding Speed: 0.5s/point (about 2800 units of 18650 cells per hour)
Motor Drive Speed: 1000mm/s
Maximum Battery Cell Loading Capacity: X direction: 26; Y direction: 26
Capable File Group Storage: 100 groups
Operating System: Embedded system human-machine interface
Transmission Mode: Taiwan precision screw with guide rail
Driving Mode: Stepper servo motor
Repeat Positioning Accuracy: ±0.02mm
Dimensions: L1020mm × W910mm × H1770mm
Power: 4000W
Machine Weight: 350KG
Maximum Bearing Weight of Y-axis: 50KG
Input Power Supply: Single-phase AC380V/50Hz
Air Source: 0.4–0.6MPa
ACEY-D300B can be used in electric tool battery, torsion car battery, Energy Storage Battery Pack, Scooter Electric Vehicle Battery, etc. Compared with manual spot welding, the efficiency and accuracy of welding have been greatly improved.
