XY Axis Travel: 500mm (customizable)
Motor Transmission Speed: 300mm/s
Operating System: Industrial computer + smart camera
Transmission Mode: Assembly line
Target: 18650 battery positive and negative pole detection
Testing Platform: Customized
Optical System: High magnification CCD camera, industrial lens, industrial optical system
Whole Machine Power: 500W
Whole Machine Weight: ~150KG
Maximum Carrying Weight: ~30KG
Input Power: Single-phase AC 220V/50Hz
CCD solder joint detector is an automatic equipment for lithium battery processing, which has the functions of automatic positive and negative pole detection, positive and negative solder joint detection, solder joint defect differentiation, automatic discharge, etc.
