Input power: AC 220V ±10% / 50Hz
Input active power: 25W
Input Resistance: ≥1MΩ
Resolution: AD: 16bit;DA: 16bit
Voltage
Per Channel Voltage Range: 25mV~5V
Discharge Min Voltage: 0V
Accuracy: ±0.05% of FS
Stability: ±0.05% of FS
Current
Per Channel Current Range
Range one:5uA~1mA;
Range two:1mA~25mA;
Range three:25mA~50mA
Accuracy: ±0.05% of FS
Constant Voltage Cut-off Current: 2uA;0.05mA;0.1mA
Stability: ±0.05% of FS
Power
Per Channel Output Power: 0.05W
Stability: ±0.1% of FS
Time
Current Response Time: (0~Full Range)<1ms
Step Time Range: ≤(36524)Hour/Step
Data Recording
Recording Condition
The minimum time interval:100ms
The minimum voltage interval:10mV
The minimum current interval:2uA;0.05mA;0.1mA
Record Frequency: 10Hz
Charge
Charge Mode: Constant Current Charge、Constant Voltage Charge、Constant Current and Constant Voltage Charge、CPC
End Condition: Voltage、Current、Relative Time、Capacity、-△V
Discharge
Discharge Mode: CCD、CPD、CRD
End Condition: Voltage、Current、Relative Time、Capacity
Pulse
Charge: CCC
Discharge: CCD
Min Pulse Width: 500ms
Pulse Number: Each pulse step supports 32 different pulses
Automated Switch: Automated switch from charge to discharge for each pulse
End Condition: Voltage, Test Time
Cycle
Loop Measure Range: 1~65535 times
Max Steps Per Loop: 254
Nested Loop: Nested loop Function,Max Support 3 Layers
Protection
Software Protection
Power-down Data Protection
Off-line Testing Function
Setting Protection Condition,Setting Parameter:Low Voltage limit、Upper Voltage limit、Low Current limit、Upper Current limit、Delay Time
Noise: <85dB
Channel Features
Constant Current Source and Constant Voltage Source with Independent pairs of Closed-loop Structure
Channel Control Mode: Independent Control
Voltage and Current Testing Sample: 4-wire connecting
Database: MySQL Database
A Means of Communication of Upper Machine: TCP/IP Protocol
Data Output: EXCEL、TXT、Graph
Communication Interface: Ethernet Port
Per Unit Main Channels No.: 8
Working Temperature Range: 0℃~40℃
Storage Temperature Range: -10℃~50℃
Working Environment Relative Humidity Range: 30% ~ 80% RH
Storage Environment Relative Humidity Range: 30% ~ 90% RH
Dimensions: 1U,WDH:480330*45(mm)
The Button Battery Tester is suitable for all kinds of coin cell battery such as lithium battery, NI-MH battery, Zn-Mn watch battery and so on.
