Voltage Supply: Single-phase ~220V, 50Hz
Rated Power: 2KW
Surface Pad Material: Highland barley paper or PVC material
Material Specification Requirements: Maximum diameter of barley paper roll is 350mm; inner diameter of paper roll core is 72–75mm
Battery Type: 18650 battery cell, positive or negative pole automatically pasted with highland barley paper pad or PVC material
Feeding Method: Insert battery cell hopper, 400 pcs each time, available for 2 separate inserting units BNX-350 auto pasting
Pneumatic Pressure: 0.4–0.8MPa
Cushioning Power: Electric or pneumatic
Control Device: 7.5-inch touch screen, PLC programmer and servo motor
Applicable Diameter: 100mm
Speed: 4000–4500 pcs/hour, 4 pcs per punch
Dimensions: L1110mm × W710mm × H1580mm
Machine Weight: 200Kg
Knife Mold: Slow-moving wire processing method, high precision; knife mold coated once every 5000 cycles to remove adhesive residue
Features
1. The equipment has a compact structure design, beautiful appearance and small space occupation.
2. The equipment is equipped with universal movable casters, which makes it easy to move and transport the equipment.
