Applicable Cell Types: Cylindrical cells: 32135, 33140, 38121, 40135, 46140, etc.
Sorting Channels: 10 Channels
Production Capacity: Approx. 3200 cells/hour
Changeover Time: About 15 minutes
Internal Resistance Tester: Optional different brands/models
Barcode/QR Scanning: Optional
MES Communication: Supported
Power Supply: 220V, 50Hz/60Hz
Total Power: ≤1.5KW
Air Pressure: 0.5～0.6MPa
Ambient Temperature: -30°C ~ 50°C
Humidity: ≤90%
Noise Level: ≤80dB
Grounding Type: Direct grounding
Installation Environment: Flat, vibration-free, no strong electromagnetic interference
Machine Dimensions: L2331 × W1055 × H1300mm
Machine Weight: 246KG
Machine Color: Computer white (customizable)
Product Features
Suitable for large cylindrical lithium battery sorting and matching
Industrial computer + motion controller control system
High-precision servo motor operation
Compatible with various brands and models of internal resistance testers
Automatic data collection, analysis, and storage
Independent NG cell rejection function
MES system integration supported
QR code, barcode, and side scanning functions available (optional)
Sticker sorting can operate independently or inline with production lines
Fast model changeover within approximately 15 minutes
Compact structure with elegant industrial design
Easy movement with universal caster wheels
Stable performance and low maintenance design
Ideal for EV battery, ESS battery, and 3C battery pack production
