Unwinding: The unwinding air shaft is fixed, and the unwinding tension uses automatic unwinding with constant tension
Fixed length cutting speed: 5~250mm/s
Chasing color cutting speed: 5~150mm/s
Unwinding diameter (Max): 250mm
Burr condition: ≤25um
Power supply: 220V/50Hz
Power: 1.2KW
Compressed air: 0.5MPa～0.8MPa
Scope of application: Width 300mm, length 1～9999mm cutting
Cutting accuracy: Fixed length uses servo system and color mark sensor tracking, high precision, cutting accuracy within adjustable range ±0.3mm
Overall equipment size: L710 × W710 × H1000mm (guide plate length 800mm, total length 1500mm)
Weight: About 240kg
1. The cutting length, quantity and speed can be set arbitrarily, and can be cut separately.
2. Unwinding automatically adjusts the tension.
3. Continuous cutting, fixed length and cursor tracking two modes are optional, adapt to multi-segment cutting, the compensation before and after the incision can be set.
4. The width is 10~300mm, and the length is set arbitrarily within 1~9999 mm.
5. The machine adopts PLC man-machine interface control, easy to use and operate.
6. Exquisite appearance, the sheet metal adopts three-dimensional geometric design, which is simple and beautiful.
7. Easy to operate, safe and reliable, small size.
