Maximum Output Power of Transformer: 35KVA
Floating Voltage: 10V
Control Mode: Constant current control
Cooling Mode: Forced air cooling
Setting Data Groups: 99 groups
Application: Electronic parts, battery nickel plate, enameled wire, sensor wire, halogen lamp, etc.
Maximum Thickness of Parallel Welding: 0.03mm~0.5mm
Maximum Thickness of Upper and Lower Butt Welding: 0.3mm + 1mm
Machine Weight: 23.5kg
External Dimensions: L810mm × W610mm × H1220mm
Input Power: AC220V±10% 50/60Hz
Transistor Welding Power Supply
Communication Interface: RS485
Independent External Touch Screen Interface: Optional external 7-inch touch screen (DMT80480T070-18WT), communication mode RS485
External Control Function: Can be controlled by external industrial computer/PLC and cooperate with automatic machine production
Dimensions: L430mm × W185mm × H400mm
Weight: 25kg
Working Voltage: Single-phase AC220V±10% 50Hz
Output Voltage: 1-6V DC
Maximum Short-circuit Output Current: 10000A
Cooling Method: Forced air cooling
Valve Power Supply: DC24V±10%, current <150mA
Environment Temperature: -10℃~55℃
Relative Humidity: Below 80%
Features
Panel Microcomputer control, high precision welding machine with plc display panel.
Optimized structure design, beautiful appearance, compact and reasonable structure, small size and large power.
Industrial circuit design, safe and reliable.
