RTBW: 80 MHz (opt. 120 MHz) I/Q
Speed: 300/440 GHz/s
I/Os: 1 Rx (opt. 1 Tx)
Frequency range: 10 MHz to 6 | 8 GHz
Real-time bandwidth Rx: Up to 245 MHz I/Q – via 2 x USB
Real-time bandwidth Tx: 120 MHz I/Q
POI: Up to 97 ns (FFT-based), 10ns (direct I/Q-based)
Max. power Rx: +23 dBm
Max. power Tx: +20 dBm
DANL(internal pre-amp on): Typ. -170 dBm/Hz
Amplitude accuracy (typ.): Typ. +/- 0.5 dB (compensated by FIR filter)
USB streaming connection: One or two USB 3.0 (USB 3.1 Gen1; USB 3.2 Gen1)
USB bandwidth (2 x USB 3.0): Up to 784 MBytes/s sustained throughput to PC
Frequency reference accuracy: 0.5 ppm (5 ppb via OCXO option)
RBW (resolution bandwidth): 62 mHz to 200 MHz
Measurement units: Over 20 (e.g. dBm, dBμV, V/m, A/m, W/m², dBμV/m, W/cm²)
Detector: Min, Max, AVG, Peak, QPeak
Attenuator range: 50 dB / 70 dB (0,5 dB steps)
Traces: Over 20 (e.g. ACT, AVG, MAX, MIN, QPEAK)
Measurement modes: True IQ or Power/Frequency data
Trigger: Cursor, Measurement, Density
ADC: Dual 2GSPS 16 Bit
DAC: 2GSPS 14-Bit (16-Bit via oversampling)
GPS: GPS/QZSS, GLONASS, BeiDou and Galileo (concurrent reception)
GPS synchronisation: +/- 10ns timestamping in each data packet
External frequency reference input: typ. 10MHz, 3,5VRMS into 50 Ohm (SMB-connector)
FPGA: XC7A200T-2
DSP processing: 930 GMACs
SDRAM: 2 GB
Temperature range (operation): 0 °C to +50 °C (extended -40 to +75 °C)
Dimensions: 210 x 115 x 30 mm
Weight: 850 g
Power: USB 3.2 Gen 1 Type-C PD 3.0
Power consumption: Typical 15 W
