Bandwidth: 250 MHz - 7.125 GHz, 24 - 53 GHz
RTBW: 60 MHz
Speed: 500 GHz/s (optional 3THz/s)
I/Os: 2 Rx
Real-time bandwidth Rx: 60 MHz via 1x USB
Max. power Rx: +23 dBm
Max. power Tx: +20 dBm
DANL (internal pre-amp on): Typ. -170 dBm/Hz
Amplitude accuracy (typ.): Typ. +/- 0.5 dB (compensated by FIR filter)
USB streaming connection: 1x USB 3.1 or 3.2 PD
RBW (resolution bandwidth): 62 mHz to 200 MHz
Measurement units: Over 20 (e.g. dBm, dBμV, V/m, A/m, W/m², dBμV/m, W/cm²)
Detector Min, Max, AVG, Peak, QPeak
Attenuator range: 50 dB / 70 dB (0.5 dB steps)
Traces: Over 20 (e.g. ACT, AVG, MAX, MIN, QPEAK)
Measurement modes: True IQ or Power/Frequency data
ADC: 2GSPS 16 Bit
Temperature range (operation): 0 °C to +50 °C (extended -40 to +75 °C)
Dimensions: 210 x 115 x 30 mm
Power: USB 3.2 Gen 1 Type-C PD 3.0
Power consumption: Typical 10 W
