3S Telecom OCID-100B ຕົວລະບຸສາຍແສງ (1550 nm, 28 dB)

Measurement mode: Single fiber test

Wavelength: 1550 nm

Minimum output power of light source: –15 dBm

Unidirectional loss of optical cable: 28 dB

Maximum detection distance: 100 Km

Single-to-noise ratio: >25 dB

Optical fiber interface: SM

Optical fiber connector: FC/APC

Screen: 5.6-inch touchscreen

Input mode: LCD touchscreen + keys

Output mode: Visual: vibration amplitude, pulse mode

Power supply: 12 V DC/3 A

Lithium polymer battery: 7.4 V, 10.4 Ah, continuous Working hours: ≥ 14 hours

Power: ≤6 W

Dimensions (H×W×L): 65 mm × 150 mm × 235 mm

Weight: 1.5 Kg (batteries included)

Operating temperature: 0˚C to 45˚C

Storage temperature: -20˚C to 55˚C
