Wavelength: 800-1700nm
Fiber Connector: 2.5mm universal connector (suitable for FC SC ST)
Type of Detector: InGaAs
Measurement Range: -70~+6dBm
Uncertainty: ±5%
Calibration Wavelength: 850/980/1300/1310/1490/1550/1625/1650(nm)
Display Resolution: Linear display: 0.1%, logarithmic display: 0.01 dBm
Frequency Identification: 270Hz / 330Hz / 1000Hz / 2000Hz
Data Storage: 1,000
Visual Fault Locator (VFL)
Working Wavelength: 650nm
Output Power: 10mW
Mode: CW / 1Hz / 2Hz
Connector Port: 2.5mm universal connector (suitable for FC SC ST)
Optical Light Source (OLS)
Wavelength: 3155: SM 1310/1550nm ±20
Type of Laser: FP-LD
Spectral Width: 5nm
Output Power: ≤-5dBm
Stability: ±0.05dB / 30min
Mode: CW / 270Hz / 330Hz / 1000Hz / 2000Hz
Power Regulation: 0 ~ 6dB, 1dB / step
Connector Port: FC/PC
General Information
Power Supply: 3pcs AA Battery
Automatic Shutdown Time: 10min
Operating Temperature: -10~+50°C
Storage Temperature: -40~+70°C
Relative Humidity: 0 ~ 95% No Condensing
Instrument size: 186 x 100 x 50mm
Weight: 240g
