3ctest S16C4000 Impulse Current Generator (0.5 kA ~ 40 kA)
Test Current: 0.5 kA ~ 40 kA
Current Waveform:
Rise time: 8 μs, ±10%
Duration: 20 μs, ±10%
Polarity: Positive/ negative/ alternative
Source Impedance: 0.4 Ω
Repetition (time for single pulse): 11 s ~ 99 s (The minimum time is subjected to test voltage)
Counter: 1~999
Sync.: 0° ~ 360°（45 Hz ~ 65 Hz）
Trigger Mode: Manual, Auto, External Trigger
- General Parameters:
Display Screen: 5.7” TFT touch screen
Working Power: AC 110 V/220 V（±10%）, 50 Hz /60 Hz (220 V in mainland China）
Fuse: 10 A
Max. Power: 300 W
Communication Mode: Ethernet LAN, RJ45
External Control Mode: 25-pin parallel port cable
External Trigger Input: BNC, 5 V TTL, the node is open, oscilloscope can trigger the product when internal circuit is closed.
Running Control Input: BNC, 5 V TTL
Failure Detection: The failure information will be displayed on LCD in front panel when failure occurs and interrupt the working of instrument.
Working Status Indication: LED indication and LCD display on front panel
Earthing Mode: Flat earth line
EUT Power Injection Line: φ4 mm or φ6 mm banana plug
Dimension: 35U
Weight: Approx. 210 kg
Ambient Temperature: 15 ℃ ~ 35 ℃
Relative Humidity: 45% ~ 75%
Atmospheric Pressure: 86 kPa ~ 106 kPa
