- General data:
Display screen: 5.7 inch TFT touch screen
Power supply: 110V/220V, ±10%, 50/60Hz, default AC 220V 50Hz
Fuse: 6A
Max. Power consumption: 200W
Size: 19 inch/6U
Weight: Approx. 35Kg
Temperature: 15–35℃
Humidity: 45%–75%
Air pressure: 86kPa–106kPa
- Technical parameters:
Output voltage for open circuit（PK1): 0.25 kV–6.0kV ± 10%
Oscillatory frequency for open circuit voltage（1/T): 100 kHz ± 10%
Front time for open circuit voltage（T1,10%-90%): 0.5us ± 30% at PK1
Decay ratio for open circuit voltage:
40%<(PK2)/(PK1)<110%
40%<(PK3)/(PK2)<80%
40%<(PK4)/(PK3)<80%
Front time for shot circuit current (T2, 10%-90%): ≤1us at P1
shot circuit current（P1) for open circuit voltage(PK1) is 6000V: 500A ± 10% at 12Ω; 200A ± 10% at 30Ω
Pulse interval: 1s-99s
Number of test : 1-9999
Output impedance: 12ohm, 30ohm automatic switch
Trigger mode: Automatic, manual and external
Synchronization: 0°-360°, 1° step or random
Network path: Internal L1, L2, L3, N, PE, automatic switch
EUT voltage feature: AC 380V, 16A；Max: AC 450V
Test mode: programmable setup of voltage, coupling path, phase angle and other parameters
