- Technical Parameters:
As per Standards: IEC/EN 61000-4-8, GB/T 17626.8
Magnetic field strength: 1 A/m – 100 A/m (continuous), 100 A/m – 400 A/m(1 s – 10 s, short-term) (with TCXS 111 single- turn1,000*1,000 mm square coil);
Output accuracy: less than 1dB; (Minimal magnetic field strength such as 1A/m shall be calibrated manually before test）
Current waveform: 50 Hz/60 Hz sinusoid
Current distortion: <5%
Pulse interval: 1 s - 9,999s
Test duration: 1 s - 28,800s
Triggering mode: Automatic, manual or external signal triggering
Coil size: 1,000*1,000mm or other
Coil shape: Square/circular
- General Parameter:
Display screen: 5.7 inch TFT touch screen
Operating power supply: 110V/220V, ±10%, 50/60Hz (AC 220V 50Hz by default)
Fuse: 6A
Max. Power consumption: 100W
Memory space: Infinite（PC）
Communication method: Ethernet LAN, RJ45
Output method: Standard 1m coaxial cable
Dimension: 19 inch/6U/4U
Weight: Approx. 35Kg+68Kg
Operating temperature: 15–35℃
Operating humidity: 45%–75%
Operating air pressure: 86kPa–106kPa
