Current peak: 1~100kA
Stored energy: 400kJ
Charging voltage: 14 kV
Supply mains: AC220V 200A
Installation: split frame
Item: 10/350μs current wave
Output peak: 10kA,15kA,25kA,35kA,50kA,100kA
T1 front time: 10μs(<50μS)
T2 wave tail time: 350μs±10%
Reversed overshoot: none
Front oscillatory:<5%
Voltage polarity: +/-, (automatic switch)
Waveform switch: Automatic switch
Charging time: 10s~999s
Charging voltage instability: Less than 1%
External sync input: 50Hz
Trigger mode: Automatic or manual, single trigger available
Trigger malfunction rate: Less than 1%
Trigger range : 100% rated charging voltage
Phase test range: 0~360°
Operating load test: internal,0~500V,5A continuous supply
Display screen: 10 inch TFT color touch screen
Measurement display resolution: Better than 3%
DUT MOV, TVS, GDT, SPD, mains surge protection device
DUT residual voltage: <5kV
Current measurement (optional): Internal test box, Rogowski coil measurement, panel BNC output
Voltage measurement (optional): Internal test box, pure-resistance voltage divider, panel BNC output
Oscilloscope: MDO3012, optional
Insulation strength: ≤500V RMS(common port COMMON to ground reference PE)
- General data:
Power supply: AC220V±10%,50/60Hz,10A
Temperature: -10~+40℃
Humidity: 35%-85%RH (no condensation)
Ground resistance: No more than 0.5Ω
Structure: Open style, control and base separated
Size of test room: Depends on model(base)+3M*5M(control)
Control table: 1.8M(width)*1.1M(height)*1M(depth)
No conductive dust, no fire or explosion danger, no corrosive metal and insulation air. Wave form of mains voltage is sine wave. The THD is <5%
