- Technical Parameters: built-in single-phase coupling/decoupling networks
Standard: IEC/EN 61000-4-4, GB/T 17626.4
Test Voltage: 200 V ~ 8.0 kV, ± 10%
Source Output Voltage:
190 V ~ 7600 V±20%，into 1 kΩ load
100 V ~ 4000 V±10%，into 50 Ω load
CDN Output Voltage: 200 V ~ 4000 V±10%，into 50 Ω load
Source Impedance: 50 Ω±30%
Rise time:
Source port:
5 ns ±30%, into 50 Ω /1000 Ω load
CDN port:
4 ns ~ 7 ns, into 50 Ω load
Pulse Width:
Source port:
50 ns ±30%, into 50 Ω load;
35 ns ~ 150 ns, into 1 kΩ load；
CDN port:
30 ns ~ 60 ns, into 50 Ω load
Polarity: positive, negative
Frequency: 100 Hz ~ 1000 kHz
Pulse Number in one burst: ≥75
Burst Period: 1 ms – 9999 ms
Test Time: 1 s – 9999 s
CDN: Built-in /automatic,
Residual voltage: <10%
EUT Load Capacity: MAX AC 440 V 32 A, DC 1000 V 32 A
- General Parameters:
Display Screen: 5.7” TFT touch screen
Working Power: AC 110 V/220 V（±10%）, 50 Hz /60 Hz (220 V in mainland China）
Fuse: 6 A
Max. Power: 300 W
Memory Space: Infinite (PC)
Communication Mode: Ethernet LAN、RJ45
External Control Mode: D-25 pin
CRO Trigger Output: BNC, 5 V TTL
External Trigger Input: BNC, 5 V TTL
Running Control Input: BNC, 5 V TTL
External Sync. Input: 45 Hz ~ 65 Hz,
20 V ~ 500 V for voltage between dotted and undotted terminal.
0 ~ 500 V for voltage between dotted, undotted terminal and chassis.
Working Status Indication: LED indication and LCD display on front panel
Earthing Mode: Flat earth line
EUT Power Injection Mode: 4 mm2 banana plug
Monitor Output Mode: Standard 1 m coaxial cable
Dimension: 19”/ 4U
Weight: Approx. 25 kg
Ambient Temperature: 15 ℃ ~ 35 ℃
Relative Humidity: 45% ~ 75%
Atmospheric Pressure: 86 kPa ~ 106 kPa
