- Technical Parameters:
Contact Discharge: 1 kV – 20 kV（±5%）
Air Discharge: 1 kV – 20 kV（±5%）
Voltage Step: 100 V
Hold Time: ＞5 s
Polarity: Positive, negative
RC Module: LCD display
Humidity &Temperature: Built-in hygrothermograph, for recording and protection
Repetition Frequency: Single / 0.1 / 0.2 / 0.5 / 1 / 2 / 5 / 10 / 20 Hz
Trigger Mode: Manual / automatic
Pulse: 1 – 9,999
Contact Discharge: 150 pF / 330 Ω
Summary Procedure: Test according to different standard levels
Rise Time: 0.8 ns ± 25%
Quick Start Test Program: Simple and easy to reset data online
Evaluation Procedure: Contact discharge test at 20 Hz，evaluate the test points of DUT
Standard Test Procedure: According to IEC / EN 61000-4-2
- General Parameters:
Operating Temperature: 15 ℃-35 ℃
Operating Humidity: 30%-60%
Operating Air Pressure: 86 kPa-106 kPa
Operating Power: 100 V / 240 V (±10%); 50 / 60Hz;
Default configuration: 220 V, 50 Hz (for Mainland China)
Weight: Approx. 8.5 kg
Weight (EDS gun): Approx. 1.8 kg
