- General parameters:
Display screen: 5.7 inch TFT Touch Screen
Range of working power supply: AC 110 V/220 V，±10%，50/60 Hz
Fuse: 6 A
Max. Power dissipation: 200 W
Communication mode: Ethernet, RJ45
Auxiliary interface: D-sub 25 p
External trigger input: BNC, 5 V TTL
CRO trigger output: BNC, 5 V TTL
Running control input: BNC, 5 V TTL
Output of Warning lamp: 0 - 220 V AC 10 A / 0 - 48 V DC 3 A
The power depends on the types of external signal lamp
Safety circuit: Stop working when the safety circuit is not closed
Failure detection: LCD will display the failure on the front panel and interrupt instrument working
Instrument working status indicator: LED on the front panel indicates and LCD displays
Instrument grounding connection: Use flat ground wire
Detection output mode: Standard 1m coaxial cable
Size of crate （W*H*D): 19 inch/6U
Weight: Approx. 30 Kg
Temperature range: 15–35 ℃
Humidity range: 45%-75%
Air pressure range: 86 kPa～106 kPa
- Pulse magnetic field test:
Range of output magnetic field: 100 A/m～1200 A/m（single-turn 1000 mm*1000 m）
Waveform: Front time:8 μs±20%; Peak to half value:20 μs±20%
Polarity: +/-/alternate
Trigger mode: Auto, manual, external signal trigger
Pulse period: 5-99 s（the shortest time depends on the test current）
Number of test times: 1-999
Size of coil: 1000*1000
Shape of coil: Rectangle
Turns of coil: Single turn
