TRACO Power TRS 2-2412 Isolated 2W 18-36Vin 12Vout 167mA SMD Iso Reg
ຜູ້ຜະລິດ: TRACO Power Model: TRS 2-2412 - ຕິດຕໍ່ພົວພັນ
Width: 11.3 mm
Height: 7.6 mm
Length: 11.9 mm
Industry: Industrial
Unit Weight: 2.100 g
Output Power: 2 W
Input Voltage: 18 V to 36 V
Mounting Style: SMD/SMT
Isolation Voltage: 1.6 kV
Number of Outputs: 1 Output
Moisture Sensitive: Yes
Input Voltage - Max: 36 V
Input Voltage - Min: 18 V
Input Voltage, Nominal: 24 V
Output Current-Channel 1: 167 mA
Output Voltage-Channel 1: 12 V
Maximum Operating Temperature: + 90 C
Minimum Operating Temperature: - 40 C
