STMicroelectronics MP23ABS1TR MEMS Audio Sensor High performance MEMS audio sensor single ended analog bottom-port microphone
ຜູ້ຜະລິດ: STMicroelectronics Model: MP23ABS1TR - ຕິດຕໍ່ພົວພັນ
Depth: 0.98 mm
Shape: Rectangular
Width: 2.65 mm
Length: 3.5 mm
Port Type: Bottom
Tolerance: 1 dB
Output Type: Analog
Sensitivity: - 38 dB
Unit Weight: 21 mg
Mounting Style: SMD/SMT
Frequency Range: 10 Hz to 10 kHz
Termination Style: SMD/SMT
Moisture Sensitive: Yes
Sound Pressure Level: 130 dB
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.52 V
Directional Properties: Omnidirectional
Operating Supply Current: 120 uA
Operating Supply Voltage: 2.75 V
SNR - Signal to Noise Ratio: 64 dB
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
