TDK-Lambda CC1R5-1212SR-E Isolated 1.5W 12V 0.125A
ຜູ້ຜະລິດ: TDK-Lambda Model: CC1R5-1212SR-E - ຕິດຕໍ່ພົວພັນ
Width: 16.5 mm
Height: 8.5 mm
Length: 16.5 mm
Industry: Industrial
Unit Weight: 3.200 g
Output Power: 1.5 W
REACH - SVHC: Details
Input Voltage: 9 V to 18 V
Mounting Style: SMD/SMT
Isolation Voltage: 500 V
Number of Outputs: 1 Output
Input Voltage - Max: 18 V
Input Voltage - Min: 9 V
Input Voltage, Nominal: 12 V
Output Current-Channel 1: 125 mA
Output Voltage-Channel 1: 12 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
