HK Instruments DPG1,5K/PS1500 ເຄື່ອງວັດແທກຄວາມດັນທີ່ແຕກຕ່າງ ແລະການປະສົມປະສານຂອງສະຫຼັບຄວາມກົດດັນ (DPG: 0–1500 Pa; PS: 100–1500 Pa)
ຜູ້ຜະລິດ: HK Instruments Model: DPG1,5K/PS1500 P/N: 109.003.001 - ຕິດຕໍ່ພົວພັນ
Measurement range DPG (Pa): 0–1500 Pa
Measurement range PS (Pa): 100–1500 Pa
Accuracy of gauge (FS 20 °C): ±2 %
Switching difference: 80 Pa
Accuracy of switching point (Low limit typ.): 100 Pa ±10 Pa
Accuracy of switching point (High limit typ.): 1500 Pa ±50 Pa
Electrical rating, resistive load: 3 A / 250 VAC (DPG200/PS200: 0.1 A / 250 VAC)
Electrical rating, inductive load: 2 A / 250 VAC (DPG200/PS200: -)
Maximum pressure: 50 kPa
Service life: > 1 000 000 switching operations
Measuring units: Pa
Environment: Operating temperature: -5...+60 °C; 'Storage temperature: -40...+85 °C
Protection standard: IP54
