EA Elektro-Automatik ELR 10080-60 Programmable Electronic DC-Load (80V; 60A; 1500W)
ຜູ້ຜະລິດ: EA Elektro-Automatik Model: ELR 10080-60 P/N: 33200840 - ຕິດຕໍ່ພົວພັນ
DC-Input:
Voltage range : 0 - 80 V
Ripple rms CV : 10 mV BW 300 kHz
Ripple and noise p-p CV : 100 mV BW 20 MHz
U Min for IMax (Sink) : 0.8 V
Current range : 0 - 60 A
Power range *1 : 0 - 1500 W (0 - 1200 W)
Resistance range : 0.04 Ω - 80 Ω
Output capacity : 8640 μF
Efficiency up to : 94.0% *2
Isolation:
Negative DC-Pol <-> PE : ±1000 V DC
Positive DC-Pol <-> PE : +1000 V DC
*1 The value in brackets applies to the state of derating (power reduction) for 110 V AC and 120 V AC grid
*2 100% Power and 100% Output voltage
