NI PXIe-5820 PXI Vector Signal Transceiver (0 Hz ~ 500 MHz, Baseband)
생산업체: NI Model: PXIe-5820 P/N: 783967-01 - 연락처
I/O Type: Baseband
RF Generator Instantaneous Bandwidth: 1 GHz
RF Generator Frequency Range: 0 MHz to 500 MHz
RF Analyzer Frequency Range: 0 Hz to 500 MHz
RF Analyzer Instantaneous Bandwidth: 1 GHz
Generator Tuning Time (Typical): 0.38 ms
Combines a vector signal generator and vector signal analyzer with FPGA-based, real-time signal processing and control.
The PXI Vector Signal Transceiver (VST) combines the flexibility of a software defined radio architecture and RF instrument class performance. You can use the VST to test a variety of cellular and wireless standards, and you can easily expand the small PXI Express form factor to support multiple input, multiple output (MIMO) configurations. The VST software is built on LabVIEW FPGA, and features several starting points for your application including application IP, reference designs, examples, and LabVIEW sample projects.
Datasheet
