EAST TESTER ET3241 デジタルベンチトップマルチメータ (1000VDC, 750VAC, 10AAC/DC, 4 1/2 digits)
生産者: EAST TESTER Model: ET3241 - 連絡先
Display screen: 3.5” TFT LCD (resolution of 320*480)
Number of display digits: 4 1/2
Signal terminal: Front end
Fastest measuring speed: 7 readings/s
DCV: 1 uV~1000 V
ACV: 10 uV~750 V
Frequency range: 40Hz ~ 20kHz
DCI: 0.01 uA ~ 10 A
ACI: 0.01 uA ~ 10 A
Frequency range: 40Hz ~5kHz
Resistance: 0.01Ω ~20MΩ
Frequency/cycle: 0.01 Hz ~20 MHz
Capacitance: 1 pF ~ 10 mF
Mathematical functions: Relative measurement, max/min, dB, dBm, reading hold
Data storage/reading: Yes
Interfaces: USB device standard, RS232 optional
Trigger measurement: Yes
Square-wave output: Yes
Fast measurement: Optional configuration
Resistance 4-line measurement: Yes
External trigger measurement: None
AC+DC measurement: Yes
Calibration: Yes
On-off/diode: Yes
Limit test function: Yes
