VICTOR 3731 Programmable Linear Power Supply (3 channels, 195W)
Manufacturer: VICTOR Model: 3731 - Contact
Maximum power: 195W
Channel information
Three output channels, CH1CH2 adjustable
CH3 fixed gear shift
DC Output
Voltage/current rating
CH1:30V、3A，
CH2: 30V.3A
Maximum overvoltage/overcurrent setting value: 1mv-33V，1mA-3.3A
2.5V/3.3V/5V fixed output
Current output: 0-3A
Line out accuracy:<5%; Load adjustment: ≤ 15 words
Linear adjustment: ≤ 5 words
Ripple and noise (20H1z-7MHz): ≤ 2mVrms
Overload situation: 3A (all parameters of fixed gear have been listed, and the following parameters are called for voltage variable gear)
