Rational WTA5(Thin) Linear Scale (50-1000mm)
Manufacturer: Rational Model: WTA5(Thin) - Contact
Accuracy / output signal: ±（3+3LO/1000）um or above; 2 TTL squre wave 0°and 90°; Available in 4 TTL square wave 0°, 90°, 180° or 270°.
Length: 50-1000
Resolution: 0.005
Distance: 0.02mm
RI: 50mm
Working speed: 90m/min
Other info: Phase error: 90±15 / Operating temperature: 0℃-40℃ / Storage temperature: 20℃-50℃
Nominal length:
When LO=50-1000mm: 50mm/index
When LO=1000-3000mm: 100mm/index
Max. Travel ≦500mm:
Nominal length + 30mm: Length of signal cable: 2m
500:
Nominal length + 30mm: Length of signal cable: 3.5m
Max. Trave>900mm:
Nominal length + 50mm: Length of signal cable: 5m
