KEYSIGHT E8486A-201 E-Band Waveguide Power Sensor (54 ~ 95GHz, -60 ~ +20dBm)

  • Manufacturer:KEYSIGHT
    Model: E8486A-201
  • Contact
    • Request a Quotation

Power range:  -60 ~ +20dBm

Frequency range: 54 ~ 95GHz

Maximum Calibration Factor Relative Uncertainty

60 GHz to 64 GHz: 6.4%

> 64 GHz to 68 GHz: 5.7%

> 68 GHz to 74 GHz: 6.1%

> 74 GHz to 79 GHz: 7.3%

> 79 GHz to 90 GHz: 6.9%

Connector type:

50 MHz calibration port: Type N (male), 50 Ω nominal impedance

Waveguide flange: UG-387/U Flange, EIA WR-12
